Why RivonClaw?
OpenClaw is a powerful agent runtime,
but operating it directly means managing config files, local processes, provider
credentials, channel plugins, and update workflows. RivonClaw packages that
runtime into a desktop application with a local panel, provider management,
mobile/channel integrations, ecommerce workflows, and release infrastructure.
OpenClaw is the engine; RivonClaw is the desktop cockpit and business layer.
Current Features
- Desktop runtime manager: Electron desktop app that owns the OpenClaw
gateway lifecycle, local HTTP panel server, update checks, and user data.
- Local panel UI: React/Vite panel for chat, providers, channels, skills,
crons, usage, settings, account/billing, and gated ecommerce modules.
- LLM provider management: API-key, OAuth, custom OpenAI-compatible, local
Ollama, subscription/coding-plan, proxy, model catalog, reauth, and usage
surfaces.
- Channel integrations: OpenClaw channel configuration plus RivonClaw-owned
mobile chat, Weixin wrapper, event bridge, and capability enforcement plugins.
- Cloud-backed business modules: authenticated cloud GraphQL proxy, account
and billing state, TikTok/ecommerce surfaces, customer-service bridge, and
affiliate workflow support.
- Skills marketplace: browse/install cloud skills, manage installed skills,
and open the local user skills directory.
- Token and key usage: session usage aggregation plus per-key usage history
and subscription quota fetches where providers support it.
- Speech-to-text and extras: STT credentials/transcription routes plus web
search and embedding credential management.
- Dynamic tool authority: runtime tool visibility and enforcement via
generated tool specs, run profiles, surfaces, and the capability-manager
extension.
- Auto-update and release pipeline: electron-builder installers, update
manifests, draft GitHub releases, production website promotion, and CDN refresh
scripts.
Prerequisites
| Tool | Version |
|---|
| Git | any |
| Node.js | >= 24 |
| pnpm | 10.6.2 |
Quick Start
# 1. Clone the repository
git clone https://github.com/gaoyangz77/rivonclaw.git
cd rivonclaw
# 2. Clone/build the pinned OpenClaw runtime and apply vendor patches
./scripts/setup-vendor.sh
# 3. Install workspace dependencies and build
pnpm install
pnpm build
# 4. Launch in dev mode
pnpm --filter @rivonclaw/desktop dev
The desktop app starts Electron, launches the OpenClaw gateway, and serves the
panel on a dynamically assigned localhost port. In dev mode the panel uses the
Vite dev server at http://localhost:5180.
Repository Structure
rivonclaw/
├── apps/
│ ├── desktop/ # Electron main process, local APIs, gateway runtime
│ └── panel/ # React management panel
├── packages/
│ ├── core/ # Shared types, defaults, API contract, MST models
│ ├── device-id/ # Machine fingerprinting
│ ├── gateway/ # OpenClaw config, launcher, OAuth, skills, vendor helpers
│ ├── logger/ # Structured logging
│ ├── plugin-sdk/ # Helpers for RivonClaw/OpenClaw extensions
│ ├── proxy-router/ # Local proxy routing
│ ├── secrets/ # Keychain / DPAPI / fallback secret storage
│ ├── storage/ # SQLite repositories and migrations
│ ├── stt/ # Speech-to-text abstractions
│ ├── telemetry/ # Telemetry client
│ └── updater/ # Update manifest client
├── extensions/
│ ├── channel-weixin/
│ ├── rivonclaw-capability-manager/
│ ├── rivonclaw-event-bridge/
│ ├── rivonclaw-mobile-chat-channel/
│ └── rivonclaw-search-browser-fallback/
├── extensions-merchant/ # Private merchant plugins checked out in CI/dev
├── server/ # Backend, relay, website, telemetry, deploy scripts
├── scripts/ # Repo automation
├── vendor-patches/openclaw/ # Replayable OpenClaw patches
└── vendor/openclaw/ # Pinned OpenClaw checkout (generated/ignored locally)
Workspaces
The monorepo uses pnpm workspaces (apps/*, packages/*, extensions/*,
extensions-merchant/*) with Turbo for build orchestration.
Apps
| Package | Description |
|---|
@rivonclaw/desktop | Electron 40 desktop app. Owns app lifecycle, local API routes, gateway startup, config writes, storage, updater, telemetry, and cloud/CS/mobile bridges. |
@rivonclaw/panel | React 19 + Vite 6 SPA. Implements chat, provider setup, channels, extras, skills, crons, usage, settings, account, billing, and ecommerce surfaces. |
Packages
| Package | Description |
|---|
@rivonclaw/core | Shared defaults, types, API route contract, provider catalog, MST models, generated GraphQL types, and utility helpers. |
@rivonclaw/gateway | OpenClaw config writer, launcher, OAuth profile sync, channel config writer, model catalog reader, skills reload helper, and vendor helpers. |
@rivonclaw/storage | SQLite repositories for settings, provider keys, usage, chat sessions, channel accounts/recipients, mobile pairings, tool selections, and CS escalations. |
@rivonclaw/secrets | Platform-aware secret storage for API keys and OAuth credentials. |
@rivonclaw/proxy-router | Local HTTP proxy router for provider and first-party network paths. |
@rivonclaw/stt | STT provider utilities. |
@rivonclaw/telemetry | Telemetry client with opt-in app events and business telemetry channels. |
@rivonclaw/updater | Version and manifest utilities used by the desktop updater. |
@rivonclaw/logger | Shared logger setup. |
@rivonclaw/device-id | Stable device identity helpers. |
@rivonclaw/plugin-sdk | Shared helpers for extension packages. |
Extensions
| Package | Description |
|---|
openclaw-weixin | Wrapper around the Tencent Weixin OpenClaw channel with RivonClaw compatibility fixes. |
@rivonclaw/rivonclaw-capability-manager | Enforces effective tool availability for the current run context. |
@rivonclaw/rivonclaw-event-bridge | Mirrors selected OpenClaw agent events into the panel event stream. |
@rivonclaw/rivonclaw-mobile-chat-channel | Mobile chat channel plugin and relay synchronization logic. |
@rivonclaw/rivonclaw-search-browser-fallback | Guides search fallback behavior when direct search credentials are unavailable. |
Merchant-specific plugins live in extensions-merchant/* and are checked out by
CI from the private merchant extensions repository.
Scripts
pnpm build # Generate vendor artifacts, check extension deps, build all packages
pnpm dev # Run desktop + panel dev workflow
pnpm test # Run workspace tests
pnpm lint # Run workspace lint
pnpm format # Check formatting with oxfmt
pnpm format:fix # Apply oxfmt formatting
pnpm check:vendor-boundary # Verify vendor boundary rules
pnpm check:tools # Verify generated tool IDs/i18n/backend consistency
Per-package examples:
pnpm --filter @rivonclaw/desktop dev
pnpm --filter @rivonclaw/desktop test
pnpm --filter @rivonclaw/desktop test:e2e
pnpm --filter @rivonclaw/desktop dist:mac:arm64
pnpm --filter @rivonclaw/desktop dist:win
pnpm --filter @rivonclaw/panel dev
pnpm --filter @rivonclaw/panel build
Architecture
Electron Desktop
├─ Local panel server and typed REST/SSE routes
├─ SQLite storage + OS secret store
├─ OpenClaw config writer and launcher
├─ Proxy-aware cloud GraphQL/REST clients
├─ Backend subscription client
├─ Channel / mobile / CS / ecommerce bridges
└─ Auto-updater
React Panel
├─ Local REST APIs through Desktop
├─ Cloud GraphQL through Desktop proxy
├─ MST entity/runtime stores via /api/events
└─ Chat, providers, channels, skills, crons, ecommerce, settings
OpenClaw Gateway
├─ Pinned vendor runtime
├─ Vendor patches from vendor-patches/openclaw
├─ Auto-discovered extensions
└─ User-installed skills
The current Desktop ↔ Panel API source of truth is
packages/core/src/api/api-contract.ts.
The generated route reference lives at docs/API_ROUTES.md.
Data Directories
Defaults are resolved by packages/core/src/node-utils/paths.ts.
| Path | Purpose |
|---|
~/.rivonclaw/db.sqlite | Desktop SQLite database |
~/.rivonclaw/logs/ | Application logs |
~/.rivonclaw/secrets/ | File-based secret fallback |
~/.rivonclaw/openclaw/ | OpenClaw state directory |
~/.rivonclaw/openclaw/openclaw.json | Generated gateway config |
~/.rivonclaw/openclaw/agents//sessions/ | OpenClaw sessions |
~/.rivonclaw/openclaw/skills/ | User-installed skills |
~/.rivonclaw/openclaw/credentials/ | OAuth/channel/mobile credentials |
Releases
The current release flow is documented in docs/RELEASE.md.
At a high level: bump apps/desktop/package.json, trigger the manual
Build & Release GitHub workflow, run ./scripts/test-local.sh, publish the
draft GitHub Release with ./scripts/publish-release.sh, then promote website
download files and CDN state from the server/ repo.
License
MIT. See LICENSE.
